Gear pumps T-series
Gear pumps for hydraulic systems with rated pressure up to 280 bar. Gear pumps available in groups 3 and 4. Displacement from 34 cmᶟ to 150 cmᶟ. This PTO gear pumps are manufactured with cast iron. Assembling dimensions according to ISO or UNI.
Displacement:
- Group 3 - 34…100 cmᶟ
- Group 4 - 63…150 cmᶟ
- Max. continuous pressure up to 280 bar
- Max. intermittent pressure up to 315 bar
- Maximum speed up to 2800 min⁻¹
- High efficiency
- Long service life
- Assembling dimensions according ISO and UNI
- Direct installation on PTO
- Multiple pumps are avaible
- Reversible rotation is avaible
This PTO gear pumps are manufactured with cast iron. They have rear and side ports for easy installation. Ideal solution for hydraulic systems of mobile vehicles on truck chassis.
Applications:
- Tipper trucks
- Truck mounted cranes
- Aerial platform
- Loader cranes
- Municipal vehicles
Gear pumps T-series are used in hydraulic systems of mobile machines. Direct installation on PTO. Rear and side ports make easy installation. Modern technologies and many years of experience of the HYDROSILA company allow to create pumps with high efficiency for the whole working life.
Characteristics
- External gear pumps.
- Reversible rotation is avaible.
- Cast iron body.
- Outrigger bearing to withstand axial and radial loads.
- Mounting flanges and shafts according to ISO, UNI, DIN.
- Rear and side ports.
- High quality NBR seals (Viton is avaible).
- Multiple pumps are avaible (up to 2 sections).
